Structural Adhesive
Room-Temperature Structural Adhesive Paste
Model: ArmertEX AD-29
Specifications
| Adhesive type | Two-component room-temperature curing epoxy paste |
|---|---|
| Mix ratio | Part A : Part B = 5 : 2 by weight |
| Pot life | 1.5 hours @ 20°C after mixing |
| Cure schedule | 3 days @ 25°C, or 1–4 hours @ 60°C |
| Typical lap shear strength | 37.3 MPa @ RT; 19.6 MPa @ 70°C (aluminum, phosphoric-acid anodized) |
| Typical floating roller peel strength | 9.1 kN/m @ RT (aluminum, phosphoric-acid anodized) |
| Stated service temperature | -55°C to 70°C |
| Shelf life | 1 year, stored sealed in a cool, dry place |
| MOQ | Confirmed with quotation |
| Lead time | Confirmed with quotation |
| Packaging | Part A and Part B packed in sealed plastic bottles or pails; shipment conditions confirmed with quotation |
Applications
- Aluminum honeycomb to aluminum panel bonding
- Aluminum panel to aluminum panel bonding
- Stone, wood, ceramic and rigid plastic bonding
ArmertEX appears in manufacturer documentation as the product brand for AD-29.
AD-29 is a two-component epoxy paste adhesive for aluminum honeycomb-to-panel and panel-to-panel bonding.
All listed figures are manufacturer-stated typical values, not acceptance limits or third-party certification. Confirm pressure, surface preparation, test method and the applicable cure schedule for the selected bonding configuration.
The two components are supplied in sealed plastic bottles or pails. Include your required specification, test method and quality-document requirements in the inquiry so availability can be confirmed for the selected grade.
